Additional Features:

• Range: 10 MHz to 20 GHz
• Excellent directivity and test port match for precise measurements of reflection coefficient
• Time domain software for pinpointing impedance discontinuities in devices or systems
• Polar and Smith Chart displays to facilitate matching of devices in circuits
• Fast sweep rate to speed up alignment of components in production test
• Wide range of calibration kits for 3.5 mm, Type N and 7 mm connectors
• Works with standard 6200 series Microwave Test Set for easy upgrade route

The MTS uses a fully synthesized frequency source. The swept signal it provides combines the speed and convienence of an analog sweep generator with the precision of a synthesized sweep. High frequency stability and a resolution of 1 Hz ensures that even narrow filters can be measured with accuracy and confidence.

Power level is settable over a 40 dB range with a maximum guaranteed levelled power of 7 dBm. With the step attenuator option, amplitudes down to -90 dBm may be set for the characterization of amplifiers and otheractive devices.
